DAB KI 30/90 Stainless Steel Pump

Specifications

• Flow rate minimum and maximum: 10 m3/h
• Head up to: 32 m
• Glycol percentage: 30%
• Min. and max. supported liquid temperature: From -10°C to +90°C
• Maximum ambient temperature: +40°C
• Maximum operating pressure bar / kPa: 8 bar / 800 kPa
• Class of protection: IP 55
• Motor insulation class: F
• Impeller/s material: Stainless steel AISI 304

• Single phase power input: 230 V 50 Hz

• Three phase power input: 3×230 V 50 Hz / 3×400 V 50 Hz
• Power cable (m) and plug: Not available

Constructional features of the pump and motor

• Air-cooled asynchronous motor.
• Motor circuit breaker and permanent capacitor included as standard in the single-phase version.
• In the three-phase version the motor protection is responsibility of the user.
• Pump body and impeller in AISI 304 stainless steel.
• Aluminum support and carbon-ceramic mechanical seal.
• Installation: Fixed in horizontal or vertical position with the motor over the pump
