Name: DAB EUROPRO High Flow 1500 T Pool Pump 11kW | DAB EUROPRO Pump
Brand: AJm60 Self Priming Jet Pump
SKU: P-DAB-EURO-1500-11KW
Price: 97017.0 ZAR
Availability: PreOrder

DAB EUROPRO High Flow Pool Pump 1500 T 11kW

Store/AC Pumps/DAB/DAB Pool Pumps

Product Details

Brand: AJm60 Self Priming Jet Pump

Weight: 24.50 kg

EUROPRO 1500 T

High performance self-priming centrifugal electric pumps with built-in high capacity prefilter. 2 or 4 pole motor completely isolated from the water.

Extremely quiet and highly reliable, developed for water circulation and filtration in large swimming pool filtration systems. Thanks to the AISI 316 mechanical seal, they are also suitable for specific applications for the circulation of sea water.

TECHNICAL DATA

Operating range: up to 190 m3/h with head of up to 22 metres.
Pumped liquid temperature range: up to 40 °C.
Pumped liquid: clean water, slightly dirty water, slightly aggressive water (Polyhexamethylene biguanide), or chlorine electrolysis treated water.
Maximum ambient temperature: 40 °C.
Installation: horizontal position.
Special executions on requests: alternative frequencies and voltages.
Protection class of the terminal board: IP55.
Insulation class: F
Standard voltage: 3 x 230-400V 50 Hz up to 4 kW 3 x 400-690 V 50 Hz over 4 KW
IE2 motors as standard, from 0,75 kW to 5,5 kW – IE3 over 7,5 kW

CONSTRUCTION FEATURES OF THE PUMP:

Prefilter body, pump body, volute, counter volute, and pump body cover in fibre glass reinforced technopolymer resistant to swimming pool chemical agents. Polyethylene prefilter canister. Transparent polycarbonate prefilter cover with four-knob closing system.

CONSTRUCTION FEATURES

External ventilation closed asynchronous motor, 2 or 4 poles, depending on the model, with a wide power range from 3 to 15 HP.

Specification Sheet:

To see specification sheet please Click Here
